Specifications
| Model | SYB-21700 |
|---|---|
| Voltage/Capacity | 3.7V 6000mAh |
| Dimensions | 32mm (Diameter) Ă— 70.5mm (Height) |
| Discharge Current | 1C/3C/5C/10C |
| Cycle Life | 500 cycles |
| Tab Configuration | Single Tab/Dual Tabs |
| Weight | 141g |
| Cycle Count | 2000 cycles |
| Shelf Life | 1 Year |
| Operating Temperature | Charge: 0°C to 45°CDischarge: -10°C to 60°C |
| Charge Cut-off Voltage | 3.65V |
| Discharge Cut-off Voltage | 2.0V |
Certifications and Tests
UN38.3, IEC62133, UL
Overcurrent protection
Over Temperature Protection
Life cycle test
Short-circuit test
Applications
ESS
Solar power
E-bikes
UPS backup systems
