Specifications
| Model | SYB-F48-50A |
|---|---|
| Chemistry | LiFePO4 52Ah Prismatic Cell |
| Nominal Voltage | 51.2V |
| Nominal Capacity | 50Ah |
| Series/Parallel Configuration | 16S1P |
| Charge Voltage | 57.6V |
| Max Charge Current | 25A |
| Max Continuous Discharge Current | 50A |
| Peak Discharge Current | 100A (5S) |
| Operating Voltage Range | 44V to 58.4V |
| Charge Temperature Range | 0°C to 55°C |
| Discharge Temperature Range | -20°C to 65°C |
| Storage Temperature | -20°C to 40°C |
| Dimensions (L×W×H) | L360.6mm ×W 291.8mm × H138.8mm |
| Cycle Life | Cell: 2000 cycles, capacity retention ≥80%Battery Pack: 1200 cycles, capacity retention ≥70% |
| Communication & Certifications | Communication: Supports RS-485 CommunicationCertifications: Customizable per client requirements |
Certification standards and testing
UN38.3, UL 2580, and ISO 12405-2
charge-discharge
Temperature cycling test (-10 ℃ -40 ℃)
Vibration (ASTM D4169)
Overcharge
Water spray testing.
Applications
Mid-range golf carts
Corporate campus transporters
Light-duty hotel/resort vehicles
