Specification
| Model | Nominal Voltage (V) |
Capacity (Ah) |
Dimension (mm) |
Standard Charge Current (A) |
Fast Charge Current (A) |
Standard Discharge Current (A) |
Standard Discharge Current (A) |
Standard Discharge Current (A) |
Discharge Cut-off Voltage (V) |
Weight (kg) |
Cycle Life @ 80% DOD |
|---|---|---|---|---|---|---|---|---|---|---|---|
| SYB-NCM42 | 3.7 | 42 | 16*120*86 | 20 | 42 | 20 | 42 | 4.2 | 2.75 | 1.2kg | ≥500 |
| SYB-NCM52 | 3.7 | 52 | 18*148*92 | 35 | 52 | 35 | 52 | 4.2 | 2.75 | 2.2kg | ≥500 |
| SYB-NCM105 | 3.7 | 105 | 45*173*126 | 50 | 105 | 50 | 105 | 4.2 | 2.75 | 2.5kg | ≥500 |
Certifications & Testing
UN38.3, MSDS, IEC62133, CE
Thermal shock test
Aging test
Short circuit test
High-temp storage
Drop test
Application
Smart home and IoT devices
Medical electronic instruments
Industrial sensors and handheld tools
Electric scooters and mobility aids
Smart speakers, drones, GPS tracking systems
