Specifications
| Stacked Integrated Home Storage System（with inverter） | |
|---|---|
| Model | SYBHES-GMAIO1-1000 |
| Rated voltage | 51.2V |
| Rated capacity | 200Ah |
| Rated energy | 10.24kWh |
| Inverter 10kW (off-grid) | |
| Accessories | Power output cable red and black wires, communication cable wires |
| Warranty period (Year) | 5 year |
| Packaging | Cardboard box + Wooden box |
| Size mm | 600*185*1600 |
| Weight KG | 125 |
| How to operate | Keypad style |
| Gross weight KG | 126.6 |
Certifications & Testing
IEC 62040, UN38.3, CE, MSDS
Charge-discharge cycles
Insulation resistance testing
Hgh-voltage protection tests
High temperature and high humidity environment test (85 ℃/85% RH)
Industry Applications
Medium sized households: ensuring the continuous operation of core household appliances such as refrigerators, air conditioners, and water heaters during power outages
Rural housing: solving the problem of unstable power grid, using solar panels to achieve off grid power supply
Small office space: Provide backup power for the office to ensure that computers, printers, and network equipment work properly in the event of a power outage
Solar-plus-storage systems
Backup for heat pumps or EV chargers
