Specifications
| Model | SYB-F72-45B |
|---|---|
| Chemistry | LiFePO4 (Lithium Iron Phosphate) Cells |
| Nominal Voltage | 76.8V |
| Nominal Capacity | 100Ah |
| Series/Parallel Configuration | 24S1P (25 Series, 1 Parallel) |
| Charge Voltage | 86.4V |
| Max Charge Current | 10A |
| Max Continuous Discharge Current | 150A |
| Peak Discharge Current | 300A (Continuously 30S) |
| Operating Voltage Range | 60V to 86.4V |
| Charge Temperature Range | 0°C to 55°C |
| Discharge Temperature Range | -20°C to 65°C |
| Storage Temperature | -20°C to 40°C |
| Dimensions (LĂ—WĂ—H) | L637mm Ă— W300mm Ă—H243mm |
| Cycle Life | Cell: 3000 cycles, capacity retention ≥80%Battery Pack: 1200 cycles, capacity retention ≥70% |
| Communication & Certifications | Communication: Supports RS-485, CAN ,4G, GPSCertifications: Customizable per client requirements |
Certification standards and testing
UN38.3, UL 2580, IEC 62133-2
Insulation resistance test
emc testing
Fast charging test
High-frequency vibration test
Applications
Express shuttle buggies
VIP transport carts
Long-distance golf tours
