Specifications
| Model | SYB-F48-30A |
|---|---|
| Chemistry | LiFePO4 (Lithium Iron Phosphate) Cells |
| Nominal Voltage | 48V |
| Nominal Capacity | 30Ah |
| Series/Parallel Configuration | 15S52P (15 Series, 52 Parallel) |
| Charge Voltage | 54V |
| Max Charge Current | 15A |
| Max Continuous Discharge Current | 45A |
| Peak Discharge Current | 60A (10S) |
| Operating Voltage Range | 37.5V to 54.75V |
| Charge Temperature Range | 0°C to 55°C |
| Discharge Temperature Range | -20°C to 65°C |
| Storage Temperature | -20°C to 40°C |
| Dimensions (LĂ—WĂ—H) | L249mm Ă— W191.5mm Ă—H172mm |
| Cycle Life | Cell: 2500 cycles, capacity retention ≥80%Battery Pack: 1200 cycles, capacity retention ≥70% |
| Communication & Certifications | Communication: Supports One-Wire Communication, RS-485,   4G, GPSCertifications: Customizable per client requirements |
Certification standards and testing
UN38.3, CE, RoHS.
Charge discharge cycle test
Vibration simulation test
Short-circuit protection
Drop Impact test
Thermal stability test
Applications
2-seater golf carts
Small sightseeing vehicles
Private campus buggies
