Specifications
| Model | SYBP-300-M2 |
|---|---|
| Cell Type | LiFePO4 |
| Rated voltage | 12.8V |
| Rated capacity | 18Ah |
| Rated energy | 230.4Wh |
| Output | |
| AC Output Power | 300W |
| AC Output Waveform | Pure Sine Wave/Modified Sine Wave |
| AC Output Voltage | 230V/120V-50Hz/60Hz |
| USB output | USB-C Port:1× 5V/3AUSB-A Port:3× 5V/2.4A |
| Type-C output | / |
| DC output | 12V/10A |
| Wireless charging | 15W Max ( Optional ) |
| Input | |
| Adapter Input | / |
| AC input | 50W |
| Type-C input | / |
| Solar Input | 12-28V/2.5A 40W（max） |
| Car Input | 12/24V 2.5A |
| LED light | (Optional): Low light, strong light, SOS mode |
| Accessories | AC Power Cord、OEM Manual |
| Warranty period (Year) | 1 year |
| Packaging | 1：Kraft paper box2：UN outer box |
| Size mm | 217*131*147 |
| Wight KG | 3.5 |
| Gross weight KG | 3.78 |
| Packing Quantity | 1 box, 1 piece |
| Note | Life Cycles:2500+ Cycles to 80% Original CapacityOperating Temperature:14-104℉ (-10-40℃)
Storage Temperature:32-104°F (0-40°C) |
Certifications & Testing
UN38.3, CE, MSDS, IEC 62133
Salt spray test
IP54 waterproof and dustproof test
Charge discharge cycle test
thermal performance verified from -10°C to 50°C
Applications
Emergency backup
Compact solar system
Day trips & small fieldwork
Electronic teaching equipment, lighting
walkie-talkie
