Specifications
| Model | SYB-24100A |
|---|---|
| Rated Voltage | 25.6V |
| Rated Capacity | 100Ah |
| Energy Density | 2560Wh |
| Voltage Range | 21.6 – 28.8V |
| Charge Current | 50A |
| Maximum Continuous Charge Current | 100A |
| Cycle Life | 4000 cycles |
| Dimensions (L×W×H) | 502*187*242mm |
Certification standards and testing
IEC 62619,UN38.3, CE, UL 2271
85 ℃ high temperature and high humidity test
Vibration tested per ASTM D4169
Plus high-rate discharge
Carge recovery cycles
Applications
Electric boats & small EVs
Industrial carts
24V solar battery banks
