Specifications
| Model | SYBP-2400-M1 |
|---|---|
| Cell Type | LiFePO4 |
| Rated voltage | 51.2V |
| Rated capacity | 50Ah |
| Rated energy | 2560Wh |
| Output | |
| AC Output Power | 2400W |
| AC Output Waveform | Pure Sine Wave |
| AC Output Voltage | 230V/120V-50Hz/60Hz |
| USB output | USB-C1/C2 Output:PD 100WUSB-A1/A2/A3/A4 Output:4 × 5V/3A |
| Type-C output | / |
| DC output | 1 × 12V/10A（Car output）；2 × 12V/10A DC 5521（5.5mm outup） |
| Wireless charging | 2 x 15W Max( Optional )） |
| Input | |
| Adapter Input | / |
| AC Input | 1300W |
| Type-C input | / |
| Solar Input | 12-60V/12A 600W（max） |
| Car Input | 12/24V 8.5A |
| LED light | 1W (Half Bright, Full Bright, SOS) |
| Accessories | AC Power Cord、Car Charger、OEM Manual、Accessory Box |
| Warranty period (Year) | 1 year |
| Packaging | 1：Kraft paper box2：UN outer box |
| Size mm | 397*296*314 |
| Wight KG | 26.8 |
| Gross weight KG | 30 |
| Packing Quantity | 1 box, 1 piece |
| Note | *Maximum Input:1800W, with AC and Solar input Simultaneously*Life Cycles:2500+ Cycles to 80% Original Capacity
*App Control:Yes，WiFi & Bluetooth Connection IOT (Optional) *Scalability:Expandable with 4 × B256B *Small cart:Yes ( Optional ) *Operating Temperature:14-104℉ (-10-40℃) *Storage Temperature:14-113℉ (-10-45℃) |
Certifications & Testing
UN38.3, UL2580, CE
Military-grade shock test
Drop test
Vibration test
IP68 highest level waterproof and dustproof test
Charge discharge cycle test
High altitude testing (above 5000 meters)
Applications
Construction & engineering
Film production units
Medical refrigeration on the go
Large industrial equipment such as cranes and welding machines
Stage sound system, lighting control system, video playback equipment
